Many drivers prefer a manual transmission system over an automatic transmissions system in their vehicle. And yet an automatic gearbox has a lot of advantages. In this article we list up the different automatic transmission technologies and compare them in terms of fuel efficiency, production cost and driving comfort.
Like to know more about Q8 Oils and the amazing range of products they produce, the quality control and research that they put into every product?
Check out this Corporate video which provides a great background.
Q8Oils’ state-of-the-art blending plant in Antwerp is one of largest and most technically advanced lubricant production facilities in Europe. With a multi-million Euro investment just completed, the plant has a blending capacity which is scalable up to 250 million litres per annum. It enjoys excellent access to the UK and mainland Europe by highway, rail and sea. The river jetty can accommodate ships of up to 5,000 tonnes, and with 24 base oil and 42 additive tanks respectively, the plant can efficiently produce the widest range of finished lubricant products of any blending plant in Europe.
"the plant can efficiently produce the widest range of finished lubricant products of any blending plant in Europe"
Furthermore, the mega-blend vessel can manufacture batches up to 400,000 litres and the filling hall is equipped with both semi and fully automatic filling lines.
O8Oils’ stringent in-house quality control procedures and world-class technical development capabilities are additionally complemented by ISO 9001, ISO 14001 and RC 14001 certification.
Selecting The Right Grease
The application of grease can be at times very complex, although a little knowledge goes a long way. For example, in construction equipment the environment is harsh with water, dirt, poor seals and heavy loads being common. In this type of situation, you need a grease that is highly water resistant, tenacious, with good rust protection and film strength. Barium greases work well along with the lithium 12‑hydroxy greases (usually with polymers). Some specific formulations using an aluminum-complex thickener also find use here.
Bearings (ball, roller, needle, etc.) normally see much less contamination but experience wide variations in both speed and temperature. Here, you need a grease that has outstanding mechanical stability (very minor softening or hardening), excellent oxidation stability (long life) and performance over a wide temperature range. Where temperatures do not exceed 250 degrees F, the lithium 12‑hydroxy greases find the widest use. When temperatures increase or long life is required, either a lithium-complex or polyurea can be used.
Sliding or rubbing contact such as with automotive ball joints, sleeve bearings, some gears, etc., requires both extreme pressure and anti‑wear qualities along with a tenacious film to prevent squeeze-out, washout or both. In this type of application, the use of solid lubricants to aid in the prevention of wear is common, with molybdenum disulfide being the dominant solid. Here, the lithium 12‑hydroxy, lithium complex, barium and aluminum-complex greases would be good choices.
Improper selection and application of the proper type of grease to perform in the intended application is one of the biggest reasons for failure. Also at the top of the list is grease compatibility or the lack of it. As a general rule, keep similar thickeners in the same application (e.g., lithium with lithium complex). If possible, do not mix greases of different thickener types.
Especially try to avoid situations where aluminum complex, clay or silica-thickened greases may become mixed with other greases. Excessive softening is usually the result. These thickeners, while producing excellent lubricating greases, do not tolerate other greases well.
Failure of almost any grease‑lubricated part generally falls into four categories:
- The selection and application of the wrong type of grease
- Incompatibility resulting in excessive softening
- Contamination resulting in excessive wear
- Too much or too little grease applied
Remember, the lack of grease can cause failure, but too much grease is often the primary cause of failure because the excessive lubricant causes high temperatures, which in turn oxidizes the grease.
Ref: Machinery Lubrication
New Queensland Transport Requirements
A number of our customers have reported that the Department of Transport has been fining road users for the use of umarked Shackles for towing purposes. These shackles are commonly used for towing caravans, boats or trailers for securing safety chains to the towing vehicle.
To view the August 2014 Safe Towing Guide please click here.
Interestingly, the Guide says:
""The Department of Transport and Main Roads recommends that the shackles used should meet Australian Standard AS 2741-2002 “Shackles”, or another equivalent recognised standard, and have a break load limit of the shackle is rated at least 1.5 times greater than the ATM of the trailer."
It goes on to say that you can identify a shackle that meets the AS standard by viewing its marking. It needs to clearly show the manufacturer name, quality grade and load rating.
Even though the guide says that this is "recommended" we have confirmation from a number of customers that they are being booked if the shackles do not have a clear manufacturer name, quality grade stamp, load rating and the AS number displayed.
All Tranzmile outlets, including Kingaroy Machinery Centre and Black Truck Sales outlets now stock a full range of shackles that meet these requirements.
Tranzmile expands to Kingaroy
Published on: 08.04.2014
Tranzmile is pleased to announce the purchase of Kingaroy Machinery Centre. Kingaroy Machinery Centre has been servicing the South Burnett since 1945 with a proud history of providing a full range of truck, trailer and agricultural parts. With the purchase by Tranzmile, the range of products available through Kingaroy Machinery Centre has already grown, with over $100,000 in additional stock now available in store.
In addition KMC customers will see significantly improved pricing, making KMC more than competitive with suppliers in Toowoomba or Brisbane. If you live or work in the South Burnett, there really is only one destination for all of your truck & trailer parts - Kingaroy Machinery Centre.
From Monday the fourth of November, Kingaroy Machinery Centre will join Tranzmile, the aftermarket truck and trailer parts arm of the Harvey Black family’s Black Truck & Ag company which sells and services Iveco, Western Star, Isuzu and New Holland in Toowoomba, Dalby, Roma, Goondiwindi and Moree.
Managing director of Tranzmile Cameron Black said purchasing Kingaroy Machinery Centre was a logical step in the growth of their business. “We wanted an established business which had its roots in a thriving country town to expand our portfolio,” Mr Black said.
“Kingaroy Machinery Centre is a natural fit with us because it is a strong rural business with a good grounding in aftermarket truck servicing given it is a former International trucks dealer."
“With the buying power of our combined truck and parts businesses, our Kingaroy customers are going to be able to start buying locally with us, but only pay Brisbane and Toowoomba pricing. “
I think this is going to be a huge benefit for everyone doing business in the town. “Customers will pretty much straight away start seeing some very significant savings flowing through to them.” Mr Black said KMC would be expanding the centre’s already big range. “You will be able to access the huge range of products we have in Brisbane and Toowoomba, without having to make the drive to the city,” he said. “As a part of the Harvey Black Group, Neil, Angie and Paul from KMC now join our existing 22 parts interpreters, ensuring that there is very little in the way of truck and trailer parts that we cannot help our customers with.
“Black Truck Sales runs, of course, Iveco, Western Star and Isuzu truck dealerships so KMC will be particular strong in that area as well.”
Mr Black said having grown up only an hour away, near Jandowae, he might call Brisbane home now, but he is firmly a country boy. The Gehrkes congratulated Cameron and said they were pleased the business was remaining with another longstanding country family. “We wish him the best for the future,” he said. “We would also like to thank all of our customers for their loyalty they have given to this business over the past five and half years and would especially like to thank (their staff) Neil, Angie and Paul for their support and loyalty each of them have given us. “I am sure you will find the same excellent service will continue.”
Moving the largest load in West Australian mining history
Published on: 18.03.2014
Australian Mining brings you a gallery of the largest machinery move in West Australia's history, as well as video of the operation in action.
Over six days four prime move trucks towed a fully assembled Liebherr 996 excavator weighing more then 675 tonnes.
The machine was from Fortescue's Christmas Creek mine to its Solomon operations.
They travelled at speeds of 4km/hr over gravel, thanks to an additional two trucks pushing the load, and reached speeds of 6km/hr on roads.
Hauling the load the 230km to the mine took them six days, (including time spent being bogged, which was only recitified with the help of four front end loaders) working up to 15 hours per day.
It was moved on 24 twin-axle (384) Goldholfer platforms.
TomTom Telematics scoops Best Telematics System title at BusinessCar Fleet Technology Awards
TomTom Telematics, a leading provider of advanced fleet management solutions, has won the Best Telematics System title in the 2015 UK BusinessCar Fleet Technology Awards – the Techies.
As the only independent awards in fleet dedicated to technological innovation and excellence, the Techies are unique in rewarding those services, companies and products that best serve the business car marketplace.
The accolade, awarded on August 25, recognises the impact of OptiDrive 360, the company's next generation of WEBFLEET fleet management software, which empowers motorists to drive in a greener, safer style.
OptiDrive 360 provides drivers with best practice coaching on how to drive safely and efficiently before, during and after a journey. As well as giving instant feedback on harsh braking, speeding and cornering, it offers predictive driving advice using vehicle and map data to advise business drivers when to take their foot off the accelerator or shift gear, and what their optimum green speed should be.
The technology was developed following years of collaborative research with the EU ecoDriver Project.
“We were first to market with driver terminals which give direct feedback to business drivers and now we’ve raised the bar again with OptiDrive 360,“ said Giles Margerison, Director at TomTom Telematics.
“By scoring drivers on eight performance indicators, fleet managers can build up a highly accurate picture of driver behaviour which can then be used as the basis for performance reviews, training and driver benchmarking.“
BusinessCar Editor Paul Barker added: “This win in the Telematics category of the 2015 BusinessCar Techies illustrates the level of technical development TomTom’s OptiDrive 360 offers the corporate marketplace. The pioneering step of predictive advice for drivers on when to ease off for roundabouts or other hazards is particularly innovative and impressed the Techies judging panel on top of the host of useful and useable information for fleet managers.”
The Techies awards success comes hot on the heels of other recent wins for TomTom Telematics including the Belgium Fleet Innovation Award for OptiDrive 360 in June and Best Commercial Vehicle Systems Integrator at the TU-Automotive Awards in the US.
Introduction to automatic transmission systems
What is an automatic transmission system?
Vehicles need a transmission to transfer the power from the engine to the drive shaft and the differential to let the wheels turn. The transmission varies the torque, the speed and the direction by changing the transmission ratios and enables the car to start with a high torque. An automatic gearbox, or automatic transmission system, is a gearbox which, after switching on the gear, does not require manual switching.
How does an automatic gearbox work?
There are different technologies used for the automation of transmission systems.
Automated Manual Transmission (AMT)
As the name indicates, Automated Manual Transmission (AMT) systems are built based upon manual transmission systems, but the switching and the operating of the clutch is automated. Vehicles with an AMT have no clutch pedal and no real gear lever. Additional actuators are mounted on the gearbox for opening and closing the clutch and switching the synchronization rings. The full process of opening the clutch, switching to a new gear, and closing the clutch is electronically controlled. The driver can choose for an automatic mode or a manual mode. In manual mode the driver can use paddles on the steering wheel or the gear lever to switch gears.
Benefits of AMT:
- Additional functionalities like hill hold or launch control are possible
- Low fuel consumption
- Shorter switching times (compared to manual transmission)
- Low production cost
- Selespeed (Alfa Romeo)
- SMG (BMW)
- Sensodrive (Citroën & Peugeot)
- Allshift (Mitsubishi)
- Quickshift (Renault)
- Sequentronic (MB)
- Easytronic (Opel)
- MMT (Toyota)
- Daimatic (Daihatsu)
- Hondamatic (Honda)
- NAVi5 (Isuzu)
Conventional Automated Transmission (AT)
Due to the controlled oil pressure in a conventional automated gearbox, the gear speed is switched to a higher gear speed. As soon as the car slows down, the gearbox returns to a lower gear and when the car stops, the gearbox automatically switches back to the lowest gear. At standstill, it is necessary to hold the brake, or to switch the car in the ‘N’-position (Neutral).
In modern gearboxes, the transmission module controls the pressure and the switching times based on a number of sensors (of the motor and transmission). As a result, the transmission responds faster and makes the switching more comfortable.
Similar to a manual gearbox, the conventional AT has a number of fixed gears between which can be shifted. An AT shifts by connecting couplings with certain axes on the gear system, the planetary system. Each axis has a different transmission ratio, resulting in different gears.
Shifting is performed automatically by hydraulics technology. A torque convertor transfers the driving power of the gearbox to the cardan shaft.
Benefits of AT:
- Faster transmission response (compared to AMT)
- Increased gear switching comfort (compared to AMT)
- Proven technology
- Good torque capacity
- Tiptronic (Audi, Volkswagen, Porsche)
- Steptronic (BMW)
- G-Tronic (MB)
- Q-Tronic (Alfa Romeo)
- Matic (Nissan)
- Cruise-O-Matic (Ford)
- Powertech (Hyundai)
Dual Clutch Transmission (DCT)
The dual clutch transmission is a novelty introduced by Audi in the late nineties under the name of “DSG” (Dual Shift Gearbox). A Dual Clutch Transmission (DCT) has two axles on which the gear system is fitted. One axle is used for the even gears, the other axle is used for the odd gears and the reverse gear, each with its own shift mechanism and clutch. The big advantage is that the next gear is always ready. When driving in the first gear, the other axle is inactive but instantly ready for use because it moves together with the active axle. This technology allows superfast gear-switching times.
Benefits of DCT:
- Superfast, seamless gear switching
- Increased gear switching comfort
- Low fuel consumption
- DCT (BMW, Honda, Hyundai, Renault)
- DSG (Audi, Volkswagen)
- S-Tronic (Audi)
- PowerShift (Volvo, Ford)
- PDK (Porsche)
- SpeedShift (MB)
- Twinamic (Smart)
- TCT (Fiat, Chrysler)
- TC-SST (Mitsubishi)
Continuous Variable Transmission (CVT)
Unlike manual or conventional automatic transmissions, the Continuous Variable Transmission (CVT) does not interrupt the pulling force while switching. Because the CVT does not work with different gears, it accelerates smoothly. The heart of the CVT is the variator that exists of two sets of conic discs over which the belt is running. When the distance between the two disks is changed, the running radius of the belt will be adapted, allowing a seamless variable transmission ratio. A Continuous Variable Transmission is applicable for very high loads up to a torque of approximately 450 Nm.
Benefits of CVT:
- Very good gear switching comfort
- Good acceleration
- Applicable for high loads
- Variomatic (DAF)
- CVT (Chrysler, Jeep, Ford, Mitsubishi, Honda)
- Multitronic (Audi, Seat)
- M-CVT (Nissan)
- SECVT (Suzuki)
- E-CVT & HSD (Toyota)
- LHD (Lexus)
- Lineartronic (Subaru)
- VTi (GM)
- Autotronic (MB)
