SKU:- LS3000
Sale price
$1,901.33
Regular price
The Knorr Bremse Lift Axle Valve LS3000 is a pneumatic control valve used to manage a single lift axle in air-suspended semi-trailers and other heavy commercial vehicles. The valve provides fully automatic raising and lowering of the lift axle based on the pressure in the suspension air bags of the non-lift axles. It operates with a maximum system pressure of 14.0 bar and an operating temperature range from -35 °C to +80 C, supporting use in a wide range of on-road conditions. The LS3000 offers an adjustable automatic lower pressure between 2.3 and 5.8 bar and an adjustable automatic raise pressure between 0.9 and 2.7 bar, with default settings of 3.4 bar and 1.7 bar respectively. An integral damping reservoir and pre-installed push-in fittings are included, along with a mounting support. The valve can be upgraded with an LS2510 solenoid valve for traction assist and used with specified 3/2 valves for manual lowering of the lift axle.
- - Maximum operating pressure: 14.0 bar - Operating temperature range: -35 �C to +80 �C - Weight: 0.9 kg approx. - Push-in fittings size: � 8.0 mm - Nominal way through: � 5.0 mm - Adjusting range - automatic lower: 2.3 to 5.8 bar - Adjusting range - automatic raise: 0.9 to 2.7 bar - Default automatic lower lift axle pressure: 3.4 bar - Default automatic raise lift axle pressure: 1.7 bar- Used in pneumatic lift axle control systems on air-suspended semi-trailers and heavy commercial vehicles - Provides fully automatic control of raising and lowering a single lift axle based on suspension air bag pressure - Single-circuit control configuration for use in appropriate air suspension layouts - Automatic lowering pressure adjustable between 2.3 and 5.8 bar to match vehicle load requirements - Automatic raising pressure adjustable between 0.9 and 2.7 bar for controlled lift axle retraction - Default factory settings of 3.4 bar for automatic lower and 1.7 bar for automatic raise - Maximum operating pressure of 14.0 bar suits common truck and trailer air systems - Operating temperature range from -35 �C to +80 �C for use in varied Australian climates - Integral damping reservoir helps stabilise control pressure changes in the system - Supplied with pre-installed push-in fittings and mounting support for straightforward installation - Compatible with optional LS2510 solenoid valve for temporary lifting of a laden axle (traction assist) - Supports manual lowering of an unladen axle when used with specified 3/2 valves - Helps maintain correct axle load distribution by lowering the lift axle at a preset suspension pressure - Contributes to improved traction when the lift axle is temporarily raised under controlled conditions - Installation requires mounting so that no water can enter the exhaust filter - Adjustment carried out via dedicated screws for lower and raise pressures following the documented procedure
